氟碳噴涂鋁單板是由優良的高強度的鋁合金板材精制而成的。

Fluorocarbon sprayed aluminum veneer is refined from high-quality high-strength aluminum alloy sheets.

構造主要采用面板、加強筋和角碼組成。常用厚度一般在2.0mm/2.5mm/3.0mm.角碼。角碼可以直接由面板折彎、沖壓成型，也可以在面板的小邊上鉚裝角碼成型。加強筋與板面后的電焊螺釘連接，這樣一來就可以使之成為一個堅固的整體。出彩大增強了鋁單板幕墻的強度和剛性，保證了長期使用中的平整度以及抗風抗震能力。

The structure mainly consists of panels, reinforcing ribs, and corner codes. The commonly used thickness is generally 2.0mm/2.5mm/3.0mm. Corner code. The corner code can be directly bent and stamped into shape by the panel, or riveted onto the small edges of the panel to form the corner code. The reinforcing ribs are connected to the welding screws behind the board surface, which can make it a sturdy whole. Greatly enhances the strength and rigidity of aluminum veneer curtain walls, ensuring smoothness and wind and seismic resistance during long-term use.

如果是想要達到隔音保溫的效果，可以在鋁板內側安裝快捷的隔音保溫材料。

If you want to achieve the effect of sound insulation and insulation, you can install efficient sound insulation materials on the inner side of the aluminum plate.

氟碳噴涂鋁單板的優點：

Advantages of fluorocarbon sprayed aluminum veneer:

1.氟碳涂層表面處理可以使沾在氟碳鋁單板表面的灰塵以及污染更加容易被清潔，只需要一場雨水，就可以達到自潔的效果了。

1. The surface treatment of fluorocarbon coating can make the dust and pollution on the surface of fluorocarbon aluminum veneer easier to clean, and it only requires a shower of rainwater to achieve self-cleaning effect.

2.氟碳涂層可以有效地隔絕空氣與鋁合金板的接觸，從而保護鋁合金板不受到外界污染物的污染，更加持久耐用！

2. Fluorocarbon coating can effectively isolate the contact between air and aluminum alloy plate, thereby protecting the aluminum alloy plate from external pollutants and making it more durable!

3.表面涂層出彩佳的耐候性和抗紫外線性能，色彩更加持久穩定，不容易褪色。

3. The surface coating has excellent weather resistance and UV resistance, making the color more durable and stable, and not easy to fade.

4.色彩范圍比較廣，鮮艷美觀、質感好，可以大限度地滿足不同客戶的需求。

4. The color range is relatively wide, bright and beautiful, with good texture, which can greatly meet the needs of different customers.

氟碳噴涂鋁單板加工工藝處理：

Processing technology for fluorocarbon sprayed aluminum veneer:

將金屬工件(如鋁板、鋁型材)表面經過嚴格的鉻化處理后進行氟碳漆靜電噴涂，再經過230°以上的高溫烘烤流平固化，從而使金屬工件的裝飾面有一層均勻的氟碳涂層，使鋁單板的表面達到平整光滑，色澤均勻。這樣不僅可以清潔容易，維護方便，使用壽命也會更長！

After strict chrome treatment, the surface of metal workpieces (such as aluminum plates and aluminum profiles) is electrostatically sprayed with fluorocarbon paint, and then subjected to high temperature baking, leveling, and solidification at 230 ° C or above to achieve a uniform fluorocarbon coating on the decorative surface of the metal workpieces, making the surface of the aluminum veneer smooth and uniform in color. This not only makes cleaning easy, maintenance convenient, but also prolongs the service life!
